BAND SAW MACHINE
BC635A/6050/6063/6066/60100

BAND SAW MACHINE

  • Heavy-Duty Double Column Structure :
    Built with a rigid double-column design and high-strength cast-iron construction to provide maximum stability, reduced vibration, and reliable heavy-duty machining performance.
  • Superior Precision Machining :
    Engineered with precision-ground guideways and high-accuracy spindle systems to ensure exceptional dimensional accuracy, smooth surface finishing, and consistent machining repeatability.
  • Powerful Vertical Turning Capability :
    Designed for machining large diameter and heavy workpieces with high torque transmission, strong cutting performance, and dependable operation in demanding industrial environments.
  • Advanced Cross Rail & Tool Slide System :
    Equipped with a precision cross rail and durable tool slide mechanisms for smooth movement, accurate tool positioning, and efficient machining control during complex turning operations.
  • Modern CNC & Digital Control Features :
    Integrated with advanced CNC control systems, Digital Readout (DRO) options, and user-friendly operating controls for enhanced machining accuracy, productivity, and operational efficiency.
Enquiry for more Details

SPECIFICATIONS

Machine Specifications
Main specifications Unit BS280G BS315G BS460G BS650G BS850G
Cut circular @90° mm 220(8.6") 230(9") 330(13") 460(18") 600(23.6")
Cut rectangular @90° mm 250x155(10x6.1") 315x170(12.4x6.7") 460x250(18x9.8") 650x350(25.6x13.8") 850x600(33.4x23.6")
Cut circular @60° mm 100(4") 130(5") 205(8") 310(12.2") 400(15.7")
Cut rectangular @60° mm 80x95(3.1x3.7") 130x130(5x5") 205x250(8x9.8") 310x350(12.2x13.8") 400x600(15.7x23.6")
Blade size mm 27X0.9X2450 27X0.9X2450 27X0.9X3960 41x1.3x5220 54x1.6x6685
Motor KW 0.75/1.1 0.75/1.1 1.5/2.2 5.5/Servo 5.5/Servo
Packing size mm 1330x800x1100
670x400x620		 1630x870x970
720x560x600		 2300x1050x1630 3030x2280x2220 3550x2120x2660
1790x1720x1490
Net weight kg 255 350 900 2430 3950
